FOBA M2000-P Laser Engraver (2018)
Stock Number: 5162
FOBA M2000-P
Age: 2018
Condition: Good Used
The FOBA M2000 is an advanced manual workstation for precise and economical laser marking of small to large and geometrically complex workpieces, as well as batches and small series. It is available in two model variants: B (with worktable) and P (with X/Y/Z axis). Modern fiber and UV lasers can also be integrated, along with camera systems for marking alignment, verification, and code reading.
The flexible P model: Motorized axes (X, Y, Z; optionally extendable), electric lift door; suitable for batches and small parts in pallets, as well as larger components where marking positions need to be approached or multiple positions require marking.
Click to view larger photo
Request a quote on stock# 5162
| Specification | Description |
|---|
| X Axis Travel | 12.4" |
| Y Axis Travel | 7.08 - 10.03" |
| Z-Axis Travel | 13.8" |
| XY Travel Speed | 236 IPM |
| Z Axis Travel Speed | 59 IPM |
| Maximun Workpiece Size (WxDxH) | 24.4" x 19.3" x 17.7"H |
| Maximum Workpiece Weight | 66 lbs |
| Laser Head | Y.0200 20 Watt |
| Door Opening | 24.4" x 17.7" |
| Electrical Requirements | 110V/1 Phz/50-60Hz |
| Floor Space (L x W x H) | 34" x 48" x 75" |
| Weight (Approx.) | 1,389 lbs |
Equipped With:
* Laser Marking Workstation with Programmable Axes (X, Y, Z)
* FOBA MarkUS Laser Marking Software
* Yb 20 Watt Fiber Laser
* Visiion Integrated Alignment and Inspection
* Auto Door
* Windows Based System
* All Available Manuals and Accessories
